Eén gedachte over “Multratug 3, 27 & 16 met ex-D611 Duguay Trouin”

1. Hans Neels schreef:

   4 juli 2020 om 13:06

   D 611 FS Duguay-Trouin

   Laid down: February 25, 1971
   Launched: June 1, 1973
   Commissioned: September 17, 1975
   Decommissioned: July 13, 1999

   Specifications:
   Type / class: Tourville class (Type F67 ASW) large anti-submarine Frigate
   Builder: Arsenal de Lorient, Brittany, France
   Displacement: 6100 tons (full load)
   Length: 152,75 meters (501 feet 2 inches)
   Beam: 15,8 meters (51 ft 10 in)
   Draft: 6,6 meters (21 ft 8 in)
   Speed: 32 knots (59 km/h), max.
   Range: 4500 NM (8300 km) at 18 knots (33 km/h) / 1900 NM (3500 km) at 30 knots (56 km/h)
   Complement: 300

   Propulsion:
   2 x Rateau steam turbines
   4 x multi-tubular boilers
   58000 shp (43250 kW)
   2 shafts, 2 fixed propellers

   Armament:
   2 xDCN/GIAT 100mm/55-caliber Mod.68 Compact DP Gun
   6 x MM40 Exocet SSM missiles
   1 x Crotale EDIR SAM system (8-cells)
   2 x GIAT 20F2 20mm machine guns
   2 x fixed single torpedo tubes for L5 Mod.4 torpedoes

   Aviation:
   flight deck & hangar for 2 helicopters
   Westland Lynx or similar

   Systems:
   DRBV-51B surface search radar
   DRBV-26A air search radar
   DRBC-32D fire control radar
   DRBN-34 navigation radar
   DUBV-23 hull sonar
   DSBV-62C sonar
   DSBX-1 towed sonar
   ARBB-32 jammer
   ARBR-16 radar warning system
   Syva torpedo alert system
   SENIT-3 tactical data processing
   SEAO/OPSMER command support system
   2 x SYLLEX chaff/decoy launchers
